Stainless Steel 316 Tubes / SS 316 Tubing
Stainless Steel 316 Seamless & Welded Tubes Manufacturer & Exporter
SS 316 Tubes, Stainless Steel 316 ERW / EFW Tubes, ASTM A213 / A249 TP 316 Stainless Steel Welded Tubes, Stainless Steel 316 Werkstoff nr. 1.4401 / 1.4436 Tubes, Stainless Steel UNS S31600 Seamless & Welded Tubes Supplier & Exporter in India
ACE ALLOYS LLP is a known manufacturer and wholesaler of SS 316 Tubes, which contains an expansion of molybdenum that gives an enhanced consumption protection. Convergences of salt in seawater can change, and sprinkle zones can make focuses increment drastically from the shower and dissipation in Stainless Steel 316 Seamless Tubes. Our high corrosion resistance Stainless Steel 316 Welded Tubes are widely useful for various industrial structural applications such as handrails, machine supports for processing equipment and architectural supports.
The higher nickel and molybdenum content in Stainless Steel 316 EFW Tubes enables it to show preferable general consumption safe properties than Stainless Steel 304 Tubes, particularly as to setting and cleft erosion in chloride situations. Stainless Steel 316 ERW Tubes is the standard molybdenum - bearing grade, second in significance to Alloy 304 among the austenitic stainless steels 304.
Stainless Steel 316 Round Tubes are austenitic alloys that contain molybdenum, which increases their resistance to many chemical corroadents and marine environments. Stainless Steel 316 Square Tubes is a group of austenitic stainless steels with superior corrosion resistance to stainless steel 304.
Stainless Steel 316 Rectangular Tubes contains the standard molybdenum - bearing grade, second in overall volume production to Grade 304 than the austenitic stainless steels. Stainless Steel 316 Electropolish Tubes has essentially the same mechanical, physical and creation qualities as Type 304 with better erosion protection, especially to setting consumption in chloride situations.
Our large inventory includes other grades of Stainless Steel 316 Tube such as SS 316L Tube and SS 316Ti Tubes in different sizes, shapes, thickness and standards as per customized requirements of our clients. Contact us to request a quote today!
Stainless Steel 316 Tubes Specifications:
| Specifications | ASTM A/ASME SA213/A249/A269/A312/A358 CL. I to V ASTM A789/A790 |
| Dimensions | ASTM, ASME and API |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Wall Thickness | Sch 5s, 10s, 40s, 80s, 160, XXS |
| Outer Diameter - Seamless 316 Tubes | 3.00 mm - 219.10 mm |
| Outer Diameter - Welded 316 Tubes | 6.35 mm to 114.3 mm |
| Size - Seamless 316 Tubes | 6.35 mm OD - 101.6 mm OD, Guage: 20 SWG - 10 SWG |
| Size - Welded 316 Tubes | 1/2" OD - 12" OD, Guage: 25 SWG - 10 SWG |
| ERW 316 Tubes | 1/2" NB - 24" NB |
| EFW 316 Tubes | 6" NB - 100" NB |
| Form | Round, Square, Rectangular, Oval, Hydraulic Etc |
| Types | Seamless, ERW, Welded, Fabricated, LSAW Tubes |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Cut Length. |
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | Z7CND17‐11‐02 | 316S31 / 316S33 | - | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Grade specifications of Stainless Steel 316 Tubes
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 316 | S31600 | 316S31 | 58H, 58J | 1.4401 | X5CrNiMo17-12-2 | 2347 | SUS 316 |
Chemical Composition of Stainless Steel 316 Tubes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 | min. | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
| max. | 0.08 | 2.00 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
Mechanical properties of Stainless Steel 316 Tubes
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316 | 515 | 205 | 40% | 95 | 217 |
Physical properties of Stainless Steel 316 Tubes
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 316 | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
SS 316 Seamless / Welded Tubes Sizes
| 1/8" | 1/4" | 3/8" | 1/2" | 3/4" | 1" | 11/4" |
| 11/2" | 2" | 21/2" | 3" | 4" | 5" | 6" |
Available Grades of Stainless Steel Pipes & Tubes
Types of Stainless Steel 316 Tubes
- 316 Stainless Steel Tubes
- 316 Stainless Steel Tube
- 316 Stainless Steel Seamless Tubes
- 316 Stainless Steel Welded Tubes
- 316 SS Hollow Tubes
- 316 SS Square Tubes
- 316 SS Oval Tubes
- 316 SS Hydraulic Tubes
- SS 316 Seamless Tubes
- SS 316 Welded Tubes
- SS 316 Rectangular Tubes
- SS 316 Cold Drawn Tubes
- Stainless Steel 316 Seamless Tube
- SS 316 Seamless Tubes
- 316 SS Seamless Tube
- 316 Stainless Steel Seamless Tubes
- 316 SS Welded Tube
- Stainless Steel 316 Welded Tube
- 316 Stainless Steel Welded Tubes
- Stainless Steel 316 Round Tubes
- SS 316 Round Tube
- 316 SS Round Tubes
- 316 Stainless Steel Round Tube
- 316 SS Square Tube
- Stainless Steel 316 Square Tube
- 316 Stainless Steel Square Tubes
- SS 316 Rectangular Tubes
- 316 SS Rectangular Tube
- SS 316 Decorative Tube
- 316 SS Decorative Tubes
- SS 316 Sanitary Tube
- 316 SS Sanitary Tubes
- SS 316 Polish Tubes
- 316 SS Polish Tube
- SS 316 Instrumentation Tube
- 316 SS Instrumentation Tubes
- Stainless Steel 316 Rectangular Tubes
- 316 Stainless Steel Rectangular Tubes
- Stainless Steel 316 Decorative Tube
- 316 Stainless Steel Decorative Tube
- Stainless Steel 316 Sanitary Tube
- 316 Stainless Steel Sanitary Tube
- Stainless Steel 316 Polish Tube
- 316 Stainless Steel Polish Tubes
- Stainless Steel 316 Instrumentation Tube
- 316 Stainless Steel Instrumentation Tube
- Stainless Steel 316 Heat exxchager Tube
- SS 316 Heat exxchager Tubes
- 316 SS Heat exxchager Tube
- 316 Stainless Steel Heat exxchager Tubes
- SS 316 Bright Annealing Tubes
- Stainless Steel 316 Bright Annealing Tube
- 316 SS Bright Annealing Tube
- 316 Stainless Steel Bright Annealing Tubes
316 SS Tubes Available Standards
- ASTM A249 TP 316 Stainless Steel Welded Tubes
- ASTM A269 TP 316 Stainless Steel Round Tubes
- ASTM A269 TP 316 Stainless Steel Rectangular Tube
- ASTM A213 TP 316 Stainless Steel Decorative Tubes
- ASTM A249 TP 316 Stainless Steel Sanitary Tubes
- ASTM A213 TP 316 Stainless Steel Polish Tube
- ASTM A213 TP 316 Stainless Steel Instrumentation Tubes
- ASTM A249 TP 316 Stainless Steel Heat exxchager Tubes
- ASTM A213 TP 316 Stainless Steel Bright Annealing Tube
Other Standards of Stainless Steel 316 Tubes
- SS TP 316 Cold Drawn Tubes
- SS TP 316 Seamless Tubes
- AISI SS TP 316 Tubing
- SS UNS S31600 Seamless Tubing
- UNS S31600 Seamless Tube
- GOST 03Ch17N14M3 Seamless Tubes
- WERKSTOFF NR. 1.4436 Seamless Tubes
- ASME SA213TP 316 Stainless Steel Seamless Tube
- GOST 03Ch17N14M3 Welded Tubes
- SS WERKSTOFF NR. 1.4401 Welded Tubes
- UNS S31600 Round Tubes
- SS UNS S31600 Round Tube
- GOST 03Ch17N14M2 Round Tube
- WERKSTOFF NR. 1.4401 Square Tubes
- ASME SA213 TP 316 Stainless Steel Square Tube
- GOST 03Ch17N14M3 Rectangular Tubes
- SS UNS S31600 Rectangular Tube
- SS WERKSTOFF NR. 1.4436 Rectangular Tubes
- SS WERKSTOFF NR. 1.4401 Decorative Tube
- GOST 03Ch17N14M2 Sanitary Tube
- SS UNS S31600 Sanitary Tubes
- SS WERKSTOFF NR. 1.4436 Sanitary Tube
- SS WERKSTOFF NR. 1.4401 Polish Tubes
- SS UNS S31600 Instrumentation Tubes
- SS WERKSTOFF NR. 1.4401 Instrumentation Tube
- SS WERKSTOFF NR. 1.4401 Heat exxchager Tubes
- SS UNS S31600 Bright Annealing Tube
- SS WERKSTOFF NR. 1.4436 Bright Annealing Tube
For Stainless Steel 316 Tubes price list as on :
Request the latest Stainless Steel 316 Tubes Price List. Use the contact button below for Stainless Steel 316 Tubes Ready stock information and updated price list.
SS 316 Seamless / Welded Tubes Applications
| Off-Shore Oil Drilling Companies | Power Generation | Petrochemicals | Gas Processing |
| Specialty Chemicals | Pharmaceuticals | Pharmaceutical Equipment | Chemical Equipment |
| Sea Water Equipment | Heat Exchangers | Condensers | Pulp & Paper Industry |
